Spherical Sodium Silicate 70/140# Ceramic Foundry Sand

Spherical Sodium Silicate 70/140# Ceramic Foundry Sand

Détails sur le produit:

Lieu d'origine: La Chine
Nom de marque: Zhengtong
Certification: ISO9001,ISO14001
Numéro de modèle: 14#-270#

Conditions de paiement et expédition:

Quantité de commande min: 1000kgs
Prix: Negotiable
Détails d'emballage: Sac de tonne
Délai de livraison: 3-7 jours après l'ordre confirmé
Conditions de paiement: L/C, T/T, Western Union, MoneyGram
Capacité d'approvisionnement: 2500mt par mois
meilleur prix Contact

Détail Infomation

Marchandise: Sable en céramique Nom de produit: Sable en céramique de fonderie
Couleur: Brun gris PH: 7-8
Caractère réfractaire: ℃ ≥1790 Densité de la masse: 1.9-2.1g/cm3
Gravité vraie: 3.3g/cm3 Coefficient moyen d'expansion linéaire: ≤6*10-6℃-1
Matériel principal: 70% Al2O3 mn. forme: Sphericial
Surligner:

70/140# Ceramic Foundry Sand

,

Sodium Silicate Ceramic Foundry Sand

,

Spherical Sodium Silicate Sand

Description de produit

Low breakage rate​ Ceramic Foundry Sand 20/40#,30/50#,40/70#,50/100#,70/140# For Sodium

Silicate Sand



1. Product Description of Ceramic Sand

Ceramsite is also called as Ceramic foundry sand.It selects the high quality bauxite as main raw material,

then made into different size through the process of calcination, electric melting, granulation, and sieving.



Ceramic sand has high refractoriness over 1790℃, it can help to reduce the sand adhering to the casting

parts,especially when used for steel castings & stainless steel parts with higher temperature.So it is an

advanced substitute for quartz sand in casting industries.



2. Main Technical Data of Ceramic Sand

Commodity Main Chemical Index Main Physical Index
Ceramic Sand Al2O3 ≥70%
Fe2O3 ≤3%
SiO2≤18%
TiO2≤3.5%
K2O3+Na2O <1%
CaO+MgO<1%
L.O.I <0.3%
Shape: Round
Color:Gray Brown
Refractoriness:≥1790 ℃
Bulk Density:1.9-2.1g/cm3
True Gravity:3.30g/cm3
Coefficient of Expansion:0.13%
(Heat 10Minutes under 2000℃)
PH:7-8
Thermal Conductivity:0.698W/m*K
(Heated Surface 800℃)
Angle coefficient:≤1.1
(Very similar to spherical)
Water Content≤0.1%
Mud Content≤0.1%
Average Coefficient of Linear Expansion≤6*10-6-1
Grit Size 14#,20#,30#,40#,50#,70#,100#,140#,200#,270#
Section Sand 14/20,20/30,20/40,20/50,30/50,40/50,40/70,50/100
50/140,70/140,70/200,100/200,140/270,200/270
Remark Special specification can be customized



3. Main Features of Ceramic Sand

Solid Sphere: Ceramsite has solid spherical shape with smooth surface,it will provide good flowability and

filling ability.



Low thermal expansion rate: it will guarantee the casting size, provide less crack and defect and improve

the output.



Low breakage rate: ceramsite has higher density and lower breakage rate at the reclaimation,which provide

one better reclaimation rate,then reduce the production cost.



High refractoriness: ceramsite contains Min. 70% Al2O3,which provide good refractory performance,then

suitable for all kinds of metal and alloy castings.



4. Main Applications & corresponding specification:

Lost Foam casting: Ceramsite 14#,20#,30#,14/20#,20/30#,20/40#

Investment casting: Ceramsite 100/200#

Sodium silicate sand:20/40#,30/50#,40/70#,50/100#,70/140#

Casting coating: 200#,270#,200/270#

Drainage sand: 20/30#,20/40#

Alloy surface treatment:40#,140#

Resin sand:40/70#,50/100#,50/140#,70/140#,100/200#

Spherical Sodium Silicate 70/140# Ceramic Foundry Sand 0



5. How to store the ceramic sand?

Use strong moisture-proof package;

Keep it in clean, dry and ventilated place;

Keep away from dust.



6. Why Ceramic Sand can replace the chromium sand as drainage sand?

Ceramic sand has lower bulk density and price compared with chromium sand,it will reduce the sand

consumption and final production cost.



Ceramic sand also has higher cast ratio,it will effectively reduce the strength of sintering layer,it is helpfu

to drain;



Its lower thermal expansion rate can reduce the expansion rate and improve the yield rate.
